Bio Lynx

Home » Products » Bio Lynx

Bio Lynx is another masterpiece from Star Link that serve its purpose of attendance perfectly. It helps to manage the work force properly and allows you to have a look on the exact working time of employees. It features capacity storage of 5,00,000 records while 9,560 finger templates can be stored in it. For double layer security, an external color 2MP camera interface can be connected through USB port. The Bio-Lynx features multiple communication modes like RS-232, USB TCP/IP, GPRS (through SIM connection) and Wi-fi; which allows the user to get the data easily on a single click of a mouse. This device is also enabled with GPS to provide the navigational details of the device for proper mobile workforce management.

Useful for managing every purpose of workforce, Bio-Lynx is perfect device helping you by increasing the productivity of your firm. Bio-Lynx is a versatile device which can be used at any kind of set-up and work place. Bio-Lynx device is also enabled with data push technology. This device comes with LCD that displays the details of the employees, while a voice message provides the confirmation about the attendance. Bio-Lynx can also be customized according to the requirement of the client.

View Online Demo at:-

Bio LYNX – Introduction Video | Star Link Fingerprint Attendance system
https://www.youtube.com/watch?v=3FdIROiH0Og

Bio LYNX – How to Enroll Finger | ENGLISH | STAR LINK
https://www.youtube.com/watch?v=CGewuwKp1yw

Bio LYNX – How to connect fingerprint device to Wi-Fi?
https://www.youtube.com/watch?v=xD1UErjHfJU

Bio LYNX – How to enroll finger in Fingerprint Attendance System
https://www.youtube.com/watch?v=YhCvd4UbOQY

Bio LYNX – How to connect Bio Lynx with Wi-Fi | Fingerprint Attendance
https://www.youtube.com/watch?v=ClKStXYNe6s

Product Features

— Recording capacity of 5 lacs records

— 2000 – 9,560 fingerprint templates storage capacity

— External 2MP camera interface (optional at extra cost)

— Connectivity mode: RS232, USB, TCP/IP, GPRS (SIM connection) & Wi-fi (optional at extra cost)

— A-GPS for mobile workforce management

— Remote Device management

— Client/Server mode; Time Synchronization

— Access control ready

— Data Push Technology

— Voice guided message in Hindi/English

— Customization possible

Technical Specifications:-

— Processor: 32 bit RISC Micro

— User Capacity: 15,000

— Finger templates storage: 9,560 templates

— Display LCD 128×64 STN / YELLOW Graphics Display (70.70mm × 38.80mm)

— Identification Time: Less than 1 Sec

— USB Port: Support Pen drive for data transfer, USB Data Card

— A-GPS for navigation details: longitude and latitude

— Card Type Contact less: EM 4100 Card (Proximity) / (ISO / IEC 14443 A)

— Read Range / Frequency: EM Card up to 120mm / 125 Hz / up to 60 mm / 13.56 MHZ

— Communication Method: Serial Rs232, Ethernet TCP / IP Protocol, GPRS (SIM)

— Baud Rate (Selectable): (2400-115200) bps, TCP / IP Ethernet 10/100 Mbps

— Operating Temperature: 0 to 50 °C

— Operating Humidity: 10 to 90% Non-condensing

— Operating Voltage: DC 12V, 1A Through Adapter (Battery Backup Optional at extra cost)

— Keypad: 16 Key (4×4)

— Dimension / Weight: L: 182mm H: 155mm  W: 45mm / 500gms

— Visual Indicator: Red / Green LED / Message on LCD in English

— Audio Indicators:Voice Guided message (Adjustable volume).

— Customized voice greetings (Optional at extra cost)

Scanner Specifications:-

— Dedicated 400MHz DSP 2 MB RAM

— ISO/IEC 19794 Fingerprint Template

— Sensor Technology: Optical CMOS

— Sensing Area: 16.0mm × 19.0mm

— Image Size (Pixels): 272 × 320

— Image Resolution: 500 dpi

— Finger Verification Option: 1:N, 1:1

— EER < 0.1%

— Enrollment Time: 1~1.5 Sec

— Verification < 0.8 Sec

— Identification Time: 1~1.5 Sec

Standard Applications:

Time Attendances, Access Control, Payroll, Canteen, Visitor mgmt.

Other Applications:

School / College Mgt., Club Mgt., Gym Mgt., Coffee Vending Machines,
(SDK in server mode only available for any other applications for system integrator)

Hardware Interface:

Boom barrier, Turnstile, Flap Barrier

Operational Modes:-

— Only Finger

— Only Card (SMART CARD)

— Card with finger

— Finger in card ( 2 fingers in 1 Kb card, 10 fingers in 4KB card)

— Card with password

— Pin with password

— Only PIN

Note: Combination varies as per the model

Why STAR LINK is ahead of others?

— Latest technology

— Superior Standards of quality

— Customization facility

— Competitive prices

— Prompt delivery

— Excellent after sales services

— Complete solution as per need
